Castle Creations 1717-1260Kv 4-POLE SENSORED BRUSHLESS MOTOR CSE060-0082-00

This is a 1717-1260Kv 4-pole sensored brushless motor by Castle Creations.

Features:

• 4-POLE 12-SLOT sensored design that boasts exceptional efficiency and produces less heat
• Proprietary stator winding produces low internal resistance for a cooler running motor
• Oversized NMB bearings and vibration dampening system ensure the longest possible bearing life
• High-strength, high-temperature grade neodymium sintered magnets combined with high-strength Kevlar wrap ensures the integrity of the rotor is not compromised during harsh running conditions and high RPMs
• Proudly designed and manufactured in Olathe, KS USA and backed by Castle Creations' 1-year warranty

Includes:

• 4-POLE Sensored 1717-1260KV Motor
• Motor Quick Start Guide

Specifications:

• RPM/Volt (Kv): 56,000/1260Kv
• Motor Type: Brushless
• Shaft Diameter: 0.196" (5 mm)
• Number of Poles: 4
• Product Weight: 21.08oz (597.6g) with wires
• Input Voltage: 3-8S LiPo
• Battery Connector: None
• Motor Design: Inrunner
• Outer Diameter: 1.87" (47 mm)
• Adjustable Timing: Yes
• Product Length: 3.35" (85 mm)
• Application: 1/6 scale vehicles weighing up to 20lbs runnning up to 8S LiPo, Upgrade for heavier 1/8 scale, and lighter 1/6 scale vehicles
• Connector Type: 6.5mm Bullet
• Recommended Speed Control: Castle Creations Mamba Monster X 8S 33.6V
• Voltage: 7.4 - 33.6V
• Water-Resistant: Yes
